Grocery Store Case Study: Effectiveness of Entrance Mats

Grocery Store Case Study: Effectiveness of Entrance Mats

Introduction/Overview

Ronick Matting Systems provides aluminum entrance mats for a multitude of industries. Aluminum entrance mats are designed to keep your facility clean and safe by reducing dirt and debris from entering your building.

The Project

Deep cleaning an entrance matting system for a grocery store chain at a mid-large sized store in Minneapolis, MN.

Product specifics for this grocery store study.

Grocery Store Entrance Mat Details

  • Product: BaseGrid 700
  • Size: 6 feet wide by 25 feet in length
  • Carpet Insert: Exterior Brush - Exterior brush has polypropylene fibers that are more aggressive at scraping and retaining dirt.  We recommend either Heavy Duty Carpet or Exterior Brush inserts due to its 3D wiping features.
  • Finish Type: Mill
  • Frame: L- 7 Frame in Mill Finish

This grocery store is in a busy location that sees an average of 7,500 customers per week with foot and cart traffic.

Aluminum entrance mat pre-cleaning at a grocery store.

Cleaning Process

Estimated Cleaning Time: 4 Hours with 2 people.  It is recommended to clean during off-peak or closed hours.

Materials Needed:

Materials needed for cleaning

The cleaning process begins by removing the existing grids from the recess using a flat headed screwdriver to lift the individual grid sections in order to access the recess below. (The entrance grids are separated into individual smaller sections for easier maintenance).

To clean the entrance matting system- rails and carpet inserts; use a pressure washer with mild detergent and hot water to remove soil build-up.

Clean the recess by scraping hardened debris and sweeping the dirt from the concrete surface. Once all build-up has been removed the grids can be reinstalled.

Removing aluminum entrance grid sections at a grocery store to expose and clean the dirty recess well below.

The Outcome

104 pounds of dirt was removed from the recess below. The timeline between mat cleanings was 1 year.

View of all of the dirt captured below the aluminum entrance mat at this store entrance.

Perforations in this mat system allowed dirt, debris, and moisture to collect in the recess below for future cleaning. Exterior brush carpet inserts have polypropylene bristles that were used for this high traffic application.

Removing retained debris below the grocery store entrance grid for cleaning.

The carpet inserts for this grocery store were selected to maximize slip resistance. The chosen entrance mat insert color for this site was 90% black, 10% gray to camouflage accumulated dirt/debris/salt that is tracked in from outside elements.

Clean recess, ready for the aluminum entrance matting system to be put securely back into place.

Product Recommendations for this Industry

According to the Carpet and Rug Institute (CRI),an entrance mat 20-25 feet in length ensures 90% of soil/dirt is retained.  An entrance matting system that includes a fall-through feature, a brush action, and drying capabilities allows larger soil particles to fall beneath the mat surface while also trapping soil and retaining accumulating moisture. The International Sanitary Supply Association (ISSA) estimates savings of about $600 in maintenance costs for every pound of dirt prevented from entering a facility.

Overview of our findings at this store.

Summary of Findings

1 entrance mat + 7,500 customers weekly = 104 lbs. of dirt collected annually.

Completed entrance after being deep cleaned. Product Installed: BaseGrid 700
